Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 24th 2012, 6:06 pm

Ok, here are the pics from today after two thick coats last night. Coats 5 + 6.














avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 24th 2012, 6:07 pm

A lot of those particles on the hood are just dust. I didnt really wipe it off before I took the photos.

I plan to do one more coat and the 1500 grit wet sand and polish.
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 24th 2012, 6:10 pm

I have also uploaded another video of the above progress onto my youtube channel.

http://www.youtube.com/watch?v=OzyMVmt1ujk&list=PLN05l39jxcWDu9d0KY6lH5l_zOsb518kE&index=2


Last edited by AGearHead4Life on December 7th 2012, 3:36 pm; edited 1 time in total (Reason for editing : video link updated)
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 25th 2012, 12:30 pm

Well I'm headed out to inspect the pain. It was very cold last night. I think I should probably let it sit until next weekend before sanding and adding another coat. Especially since I'll be driving this to work tomorrow morning. We'll see.
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 26th 2012, 1:10 am

A couple more photos today. The sun was bright. At the right angle you can see the aluminum/metal flake.

I'm still letting that 6th coat and all the rest under it set. I figure they could use some time to set in this cold.









avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 26th 2012, 1:11 am

I also spent two hours this evening sanding the LS Fest off the sides and rear of my truck.



avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by 63Falconconvert on November 27th 2012, 11:25 am

Did you notice any change in the metalic when you wet sanded?
avatar
63Falconconvert
1000+ Poster
1000+ Poster

Number of posts : 1275
Age : 57
Location : Rochester NY
Job/hobbies : Sales welding supplies
Project : 1963 Falcon Convertible
Registration date : 2009-04-06

View user profile https://bobs1963fordfalconconvertible.jimdo.com/

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 27th 2012, 1:46 pm

63Falconconvert wrote:Did you notice any change in the metalic when you wet sanded?
I did not, but I also wasnt looking for it. I just wet sanded, dried and rolled. Didnt inspect closely.

To me though the flake is not real noticable until hit with light like in the last pics I posted. When not in direct sun light it looks a lot different. But I also havent done any sanding since the last coat in the pics above.

I will sand this weekend and apply the last coat. Once it sets for a month or so I will final sand and polish. I think then I would have your answer for you on how the flake effected it. But remember, I have no painting experience before this. So I may not be answering your question correctly.
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by 63Falconconvert on November 27th 2012, 1:53 pm

You answered it perfect so far and I think you understand my question.
Your work so far looks great, you will have awesome results in the end. Keep us posted thumbs up
avatar
63Falconconvert
1000+ Poster
1000+ Poster

Number of posts : 1275
Age : 57
Location : Rochester NY
Job/hobbies : Sales welding supplies
Project : 1963 Falcon Convertible
Registration date : 2009-04-06

View user profile https://bobs1963fordfalconconvertible.jimdo.com/

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 27th 2012, 2:58 pm

63Falconconvert wrote:You answered it perfect so far and I think you understand my question.
Your work so far looks great, you will have awesome results in the end. Keep us posted thumbs up
Thank you Much!

I will keep the updates flowing.
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by JWP on November 27th 2012, 3:33 pm

That is an in interesting approach there. I'm curious to see how the rest of the truck looks.

In response to your comments about finding dents, you can use what is called a guide coat. Typically this is a dusting of a contrasting color over primer. You sand the surface and anywhere the guide coat is left is a low area, and consequently the areas that sand down the quickest are your high areas.

Notice the black paint over the yellow primer, when done sanding the low spots will be indicated by the black paint/guide coat that remains.

avatar
JWP
Rank
Rank

Number of posts : 10
Age : 37
Registration date : 2012-11-05

View user profile

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 27th 2012, 3:39 pm

JWP wrote:In response to your comments about finding dents, you can use what is called a guide coat. Typically this is a dusting of a contrasting color over primer. You sand the surface and anywhere the guide coat is left is a low area, and consequently the areas that sand down the quickest are your high areas.

Notice the black paint over the yellow primer, when done sanding the low spots will be indicated by the black paint/guide coat that remains.
Alright, great.

So, when a low spot is found just simply fill with bondo and wipe even? Or do I have to sand down to metal? And on high spots I tap it down with a hammer then check if i tapped it too far and then fill if so?
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by JWP on November 27th 2012, 3:42 pm

AGearHead4Life wrote:
JWP wrote:That is an in interesting approach there. I'm curious to see how the rest of the truck looks.

In response to your comments about finding dents, you can use what is called a guide coat. Typically this is a dusting of a contrasting color over primer. You sand the surface and anywhere the guide coat is left is a low area, and consequently the areas that sand down the quickest are your high areas.

Notice the black paint over the yellow primer, when done sanding the low spots will be indicated by the black paint/guide coat that remains.

Alright, great.

So, when a low spot is found just simply fill with bondo and wipe even? Or do I have to sand down to metal? And on high spots I tap it down with a hammer then check if i tapped it too far and then fill if so?

Well it depends on the nature of the problem, but I would probably lean towards filling it with bondo or something similar and sanding it smooth. Metal has a funny way of bending some times and different dents may require different techniques.
avatar
JWP
Rank
Rank

Number of posts : 10
Age : 37
Registration date : 2012-11-05

View user profile

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by 63Falconconvert on November 27th 2012, 3:54 pm

If the panel is "dented" then fill it with Bondo or hammer it out. If your panel is "wavey" then load the panel with primer and block it straight.
I know this is a lot to take in and a lot to try to explain. Go to my 63 Falcon under projects and loot at some of my body work pics and look on You Tube for block sanding videos.
Hope this helps.
Bob
avatar
63Falconconvert
1000+ Poster
1000+ Poster

Number of posts : 1275
Age : 57
Location : Rochester NY
Job/hobbies : Sales welding supplies
Project : 1963 Falcon Convertible
Registration date : 2009-04-06

View user profile https://bobs1963fordfalconconvertible.jimdo.com/

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by 63Falconconvert on November 27th 2012, 4:02 pm

http://rolledon.forummotion.com/t694-68-mustang-coupe

http://rolledon.forummotion.com/t747-1963-ford-falcon

http://rolledon.forummotion.com/t420-1976-mustang-cobra

In my opinion these are the 3 best projects to look at for following a project from start to finish. Everything from welding to body repair, block sanding, painting, polishing etc.
There are many great paint jobs on this forum, look through them, ask questions.
avatar
63Falconconvert
1000+ Poster
1000+ Poster

Number of posts : 1275
Age : 57
Location : Rochester NY
Job/hobbies : Sales welding supplies
Project : 1963 Falcon Convertible
Registration date : 2009-04-06

View user profile https://bobs1963fordfalconconvertible.jimdo.com/

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by JWP on November 27th 2012, 4:03 pm

63Falconconvert wrote:If the panel is "dented" then fill it with Bondo or hammer it out. If your panel is "wavey" then load the panel with primer and block it straight.
I know this is a lot to take in and a lot to try to explain. Go to my 63 Falcon under projects and loot at some of my body work pics and look on You Tube for block sanding videos.
Hope this helps.
Bob

Bob your answer was way better than mine.

AGearHead4Life - I've heard the Eastwood videos on this topic are pretty good as well.
avatar
JWP
Rank
Rank

Number of posts : 10
Age : 37
Registration date : 2012-11-05

View user profile

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on November 27th 2012, 5:31 pm

I thank you Bob and JWP very much for taking the time to post a reply on this thread. It is very helpful and when I get home I will hopefully have time to do as you've instructed and review the three other projects that you posted. I've looked through some of the projects but was more focused of the outcome at the time. Now I'll go back and learn something.
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by cac1967 on November 27th 2012, 6:49 pm

Bob is spot on about fixing the small dent's and wavy panel's thumbs up
avatar
cac1967
400+ Poster!
400+ Poster!

Number of posts : 562
Age : 45
Location : north carolina
Job/hobbies : auto parts manager/classic and antique cars
Project : 1964 falcon,1967 mustang fastback
Registration date : 2011-06-15

View user profile

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on December 6th 2012, 5:58 pm

Alright, here's the update video. I made a boo boo..

http://www.youtube.com/watch?v=pJX7o7b0LXw


Here's a link to the whole playlist:
http://www.youtube.com/playlist?list=PLN05l39jxcWDu9d0KY6lH5l_zOsb518kE
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by JWP on December 7th 2012, 9:15 am

Do you think the issue was the fact that you let the paint sit in the jar for too long?

Either way, thanks for sharing the ups and downs.
avatar
JWP
Rank
Rank

Number of posts : 10
Age : 37
Registration date : 2012-11-05

View user profile

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on December 7th 2012, 11:44 am

JWP wrote:Do you think the issue was the fact that you let the paint sit in the jar for too long?

Either way, thanks for sharing the ups and downs.
Yes, It was close to the same time as I had done for all the previous coats, but this time it was a little warming outside. MS must have evaporated. I should have just test the paint before applying it. I probably could have just added more MS to it to fix the problem.

I hope to fix my mistake this weekend.
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on December 14th 2012, 2:01 am

I hope to get an update video up soon with the final coat. I havent final sanded it and polished yet though.

Here are a couple pics of it the day I rolled the last coat on.





avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on December 14th 2012, 2:04 am

Also, Thought I'd let yall know this truck is in this months issue of GM High Tech Magazine on page 29 in the LS Fest coverage.





avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by cac1967 on December 14th 2012, 1:59 pm

lookin good man!!! congrat's on the magazine photo and keep up the great work!!!!!!
avatar
cac1967
400+ Poster!
400+ Poster!

Number of posts : 562
Age : 45
Location : north carolina
Job/hobbies : auto parts manager/classic and antique cars
Project : 1964 falcon,1967 mustang fastback
Registration date : 2011-06-15

View user profile

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by AGearHead4Life on December 15th 2012, 11:04 am

cac1967 wrote:lookin good man!!! congrat's on the magazine photo and keep up the great work!!!!!!
Thank you Sir!


I'm trying to guestimate how long is long enough to let this paint cure before doing the final sand and buff. I've heard people say they waited a month in warmer temps. So far I'm planning to just wait a month.

Any suggestions?
avatar
AGearHead4Life
Rank
Rank

Number of posts : 55
Age : 38
Location : Huntsville, AL
Job/hobbies : Custom Cars, Guns, Computers
Project : 84 C10, 92 Camaro
Registration date : 2012-11-21

View user profile http://www.youtube.com/user/AGearHead4Life

Back to top Go down

Re: 84 Chevrolet Truck C10 5.3 Swap'd - Metal Flaked ? Dark Blue

Post by Sponsored content


Sponsored content


Back to top Go down

Page 2 of 3 Previous  1, 2, 3  Next

View previous topic View next topic Back to top

- Similar topics


Permissions in this forum:
You cannot reply to topics in this forum
